1.2510 (O1)

Annealed & Oil hardened cold work tool steel (O1)

Product features
  • 100 MnCrW 4
  • As supplied condition: Soft-annealed to max. 190 HB (650 N / mm2) Good machinability and a good combination of high hardness and toughness after hardening and tempering.
  • Applications: Blanking and stamping dies for cutting sheets up to 6 mm thickness, Threading tools, Drills, Broaches, Gauges, Measuring tools, Plastic mould Tools, Shear blades and Guide rails.

Technical data

Chemical analysis
C Si Mn Cr V W
0,95% 0,25% 1,10% 0,55% 0,10% 0,55%
